Bray SA40 External Compression Spring Check Valve Accessory

External lever compression spring accessory for rapid check valve closure, compatible with NPS 2 to 48 inches.

Genuine product assurance

We can help verify product data and purchasing details.

Model confirmation

Confirm model, connection and key options before ordering.

After-sales support

After-sales communication support is provided according to the order agreement.

Bray SA40 external compression spring check valve accessory for NPS 2" to 48" (50mm to 1200mm) check valves, featuring an external lever and compression spring configuration. This accessory promotes rapid valve closure and limits the effects of backflow during flow reversal. Suitable for multi-pump manifolds, water supply and wastewater pumping stations, mining facilities, and process fluid pipelines in steel mills.

Application scenarios

Multi-Pump Manifold Systems

SA40 Series external levers and compression springs are suitable for check valves in manifold systems, promoting rapid closure to limit reverse flow.

Pump Protection in Water Supply Pump Stations

SA40 Series external levers and compression springs are suitable for pump protection applications involving check valves in water supply pump stations, increasing valve closing speed and reducing the effects of reverse flow.

Wastewater Lift Pump Stations

SA40 Series external levers and compression springs are suitable for check valves in wastewater lift pump stations, improving closing speed to address rapid backflow during pump start-up and shutdown.

Mining Facility Piping Networks

SA40 Series external levers and compression springs are suitable for check valves in mining applications, improving valve closing response during flow reversal.

Steel Mill Process Fluid Pipelines

SA40 Series external levers and compression springs are suitable for check valves in steel mill process fluid pipelines, promoting rapid valve closure and reducing the effects of reverse flow.

Selection points

Fast-Closing and Pump Protection Applications

The SA-40 external lever and compression spring accessory is designed for check valve applications requiring rapid closure. Product documentation specifically lists pump protection, water supply pumping stations, wastewater lift stations, and header systems as applicable scenarios.

NPS 2 to 48 in. Size Compatibility

This accessory is suitable for sizes from NPS 2 to 48 in., equivalent to 50 mm to 1200 mm, and can be selected according to the corresponding check valve diameter.

Compatibility with Mining and Steel Mill Applications

Product documentation lists mining and steel mills as application scenarios for the SA-40 external lever and compression spring accessory, providing a selection reference for check valve rapid-closing requirements in these industries.

Installation & maintenance notes

Allow Installation Clearance for the External Lever and Compression Spring

Provide sufficient clearance for the external lever and compression spring during installation. Avoid interference from adjacent piping, supports, or structural components to ensure proper operation of the external mechanism and rapid valve closure.

FAQ

How do SA40 Series check valve accessories work?

The SA40 Series increases closing force through an external compression spring, enabling the valve to close faster when media flow stops and reducing surge and backflow.

What pipe size range can the SA40 Series cover during selection?

The size range is NPS 2" to 48" (50 mm to 1200 mm), covering applications from small and medium to larger pipe diameters.

What optional installation/actuation components are available for the SA40 Series?

Accessory types include external levers and compression springs, used to improve rapid-closing performance and facilitate on-site adjustment.

What typical applications is the SA40 Series suitable for?

It can be used for rapid closing, header systems, mining, pump protection, wastewater lift stations, steel mills, and water supply pumping stations.

How can the specific configuration be confirmed during actual selection?

The specific configuration must be confirmed based on the actual model and application conditions. During selection, confirm it in conjunction with information such as the medium, pressure rating, and pipe diameter.
