The Spirax Sarco WAV1 is a brass 3-way solenoid valve with G1/4 threaded connection. The valve has a maximum working pressure of 5 bar, is suitable for air or water media at 0 to 90 °C, and has an IP65 protection rating. It is specifically designed to control the actuator of the DFG300A automatic bottom blowdown valve. Through coil energization and de-energization, it achieves the admission and discharge of compressed air or water, ensuring precise control of the blowdown system.
WAV1 product photo
1 / 2
WAV1 3-Way Solenoid Valve (for DFG300A Bottom Blowdown Valve)
3-way solenoid valve, suitable for automatic bottom blowdown valves, supports multiple voltage options
Genuine product assurance
We can help verify product data and purchasing details.
Model confirmation
Confirm model, connection and key options before ordering.
After-sales support
After-sales communication support is provided according to the order agreement.
Specifications
- Valve type
- 3-way solenoid valve
- Applicable media
- Air or water
- Media temperature range
- 0 to 90 °C
- Maximum ambient temperature
- 55 °C
- Protection rating
- IP65
- Maximum cable diameter
- φ7
- Supply voltage
- 24, 110, 220/240 Vac
- Power consumption
- 30VA (inrush), 5VA/8W (continuous)
- Maximum working pressure
- 5 bar
- Response time
- Open 8-15 ms / Close 8-15 ms
- Valve body material
- Brass
- Internal parts material
- Brass
- Seal material
- Nitrile rubber
- Connection thread
- G1/4
Application scenarios
DFG300A automatic bottom blowdown valve actuator control
The WAV1 is specifically designed for the DFG300A automatic bottom blowdown valve, serving as a 3-way solenoid valve to control its actuator. When the coil is energized, air or water is admitted to the actuator; when the coil is de-energized, compressed air is discharged to the atmosphere or the medium is drained.
FAQ
What scenario is the WAV1 solenoid valve mainly used for?
The WAV1 is a 3-way solenoid valve for the DFG300A automatic bottom blowdown valve, and can be used with an actuator for control.
What is the working principle of the WAV1?
When the coil is energized, the valve admits air or water to the DFG300A actuator; when the coil is de-energized, it discharges compressed air to the atmosphere, or drains water under water medium conditions.
What media and operating conditions is the WAV1 suitable for?
The applicable media are air or water, the media temperature range is 0 to 90 °C, and the maximum working pressure is 5 bar. The specific configuration must be confirmed according to the actual model and application conditions.
What are the requirements during installation of the WAV1?
It can be directly installed on the DFG300A actuator through connection accessories, or installed away from the actuator. When the medium is water, the outlet should be connected by piping to the discharge point.
What are the main technical parameters of the WAV1?
Optional voltages are 24, 110, 220/240 Vac; inrush power consumption is 30VA, continuous power consumption is 5VA/8W; enclosure rating is IP65 cable connector. Connection specification is G1/4, weight is approximately 0.4 kg.
